Spherical, and various shapes of lollipop production line

FOB Reference Price:Get Latest Price
US $20,000-80,000 / Sets | 1 Set/Sets Candy Making Machine (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
LFMJ
Model Number:
BSFD-II
Application:
Candy
Voltage:
380V
Power(W):
30-45kw
Weight:
4500
Dimension(L*W*H):
13m(L)x2m(W)x2.7m(H)
Certification:
ISO9001
Warranty:
1 Year
After-sales Service Provided:
Engineers available to service machinery overseas
Keywords:
Candy Making Machine
Compressed air consumeption:
0.5m 3 /min
Name:
Candy Making Machine
Air pressure:
P=0.4-0.6MPa
Water consumption:
2200(L/h)
Weight of machine:
6000kg
Steam consumption:
150kg/h
MOQ:
1
Supply Ability
Supply Ability:
20 Set/Sets per Month Candy Making Machine
Packaging & Delivery
Packaging Details
Ocean wooden box packaging
Port
Shanghai, China
Lead Time :
40-----65day
Product Description



Introduction:
Toffee production line is based on the recent changes in production and consumption of candy market, with the improvement of people's living standards, the requirements of the candy flavors are the emotional, low sugar, more color, the development needs of nutrition and health. Our introduction of foreign technology development toffee production equipment.
The production line mainly consists of sugar pots, buckets, toffee special boiling pot, casting units, cooling tunnels. Can produce sandwich toffee, toffee sandwich (EcoWater lotus) and other sweets.
Features:
* PLC controlled automatic programming boil sugar temperature, time, pouring temperature and casting speed;
* 9.7-inch LED touch screen display easier to operate;
* Production capacity by 150 kg to 450 kg per hour;
* Frequency Control sugar flow;
* Online completed flavors, colors, quantitative acid filling mix;
* Conveyor belt, cooling system, dual release mechanism to ensure the release;
* The entire production line according to the standard, in line with food hygiene requirements GMP.



Specification:

Model

LKK229A

LKK229B

LKK229C

LKK229D

Capacity

150kg/h

300kg/h

450kg/h

600kg/h

Max Candy Weight

6g

6g

6g

6g

Depositing Speed

55-65n/min

55-65n/min

55-65n/min

55-65n/min

Steam Requirement

250kg/h, 0.5-0.8MPa

300kg/h,0.5-0.8MPa

400kg/h, 0.5-0.8MPa

500kg/h, 0.5-0.8MPa

Compressed Air Requirement

0.2m3/min,
0.4-0.6MPa

0.2 m3/min,
0.4-0.6MPa

0.25 m3/min,
0.4-0.6MPa

0.25 m3/min,
0.4-0.6MPa

Working Condition

(Temp)20-25°C (Humidity)55%

(Temp)20-25°C (Humidity)55%

(Temp)20-25°C (Humidity)55%

(Temp)20-25°C (Humidity)55%

Electric Power Needed

32Kw/380V

39 Kw/380V

48 Kw/380V

75 Kw/380V

Total Length

17m

17m

18m

18m

Gross Weight

3500kg

4000kg

4500kg

5000kg
